Microscopy Cameras >> Micrometrics Cameras
519MU 5.0 MegaPixel Camera for Fluorescent Microscop with Micrometrics SE software

Super Light Sensitivity for Fluorescent Microscopes


Resolution 5.0 MP
Power USB Bus
Bit Depth 12-bit Digitization & Processing
8-bit Monochrome Uncompressed Output
Master Clock 48MHz
Enclosure Die Cast Aluminum
Microscope Interfacing Stainless Steel C-mount
Recommended Video Adaptor   0.4X
Sensor Technology CMOS
Pixel Array 2592H x 1932V Arbitrary Simultaneous Windowing, Binning
& Sub-sampling
Sensitivity 1.64V/Lux-Second at 550nm
Pixel Size 2.2m x 2.2m
Signal-to-Noise Ratio 38.1dB
Imaging Area 5.70mm x 4.28mm
7.13mm Diagonal
Electronic Shutter Type Rolling
Frame Rate 7FPS at Full Resolution
Proportional to Window Size/Decimation Factor
Maximum Exposure Time 76 Seconds
OS Compatibility 32-bit & 64-bit Windows 7; 32-bit Windows Vista & XP
IR Filter BP645
